Medium sized plate feeder is widely used in building materials, metallurgy, electric power, coal, chemical industry, foundry and other industries, especially suitable for conveying some solid materials with high temperature, large size, sharp edges and strong grinding ability.

The medium-sized plate feeder hauls the chain through the driving device and connects the chain plate to transport materials forward. The thickness of the chain plate can be determined according to the site requirements. If the conveying capacity and feeding capacity are large, the thickness of the chain plate will be increased, which is specially used for conveying small pieces of materials.

1. Allowed bulk density of bulk and granular materials: < 2400 kg / M ³.

2.The particle size of material is less than 400mm.

3.The material temperature is not more than 400 ℃;

4.Layout form: various, horizontal, and inclined layout; The inclination angle is not more than 25 degrees.

5.Conveying length: generally, 5-10m, the longest is less than 20m.

6.Traction chain: pitch plate pin roller chain, heat treatment, good wear resistance, high tensile strength, long service life.

7.Chain plate: the stamping tank body is adopted to make the material connection more stable, and the tank bottom plate is overlapped by circular arc to reduce material leakage.

8.Drive: the motor can adopt speed regulating motor, which can be adjusted manually. The speed is 0.3 ~ 0.5m/min, which is widely used and runs stably, so as to select the conveying capacity more reasonably.

9.Closed form: the default is open conveying material, the dust is large, if there are environmental protection requirements, can be made into a fully closed plate feeder.
