[Introduction]: The DZS series linear vibrating screen is a screen box along oriented linear reciprocating motion for fine screening.
[Capacity]: 20 ~ 300t / h
[Improved]: The screen angle of the DZS series line vibrating screen is adjustable. The vibrating motor is used as a vibration exciter and low energy consumption.
| Model | Screen Area m2 | Amplitude mm | Motor | Power kw | Revolution rpm | Weight kg |
| DZS0410 | 0.4×1.0 | 2~4 | YZO-3-6 | 0.25 | 960 | 650 |
| DZS0412 | 0.4×1.2 | 2~4 | 700 | |||
| DZS0415 | 0.4×1.5 | 2~4 | 760 | |||
| DZS0612 | 0.6×1.2 | 3~5 | 865 | |||
| DZS0718 | 0.7×1.8 | 3~5 | YZO-10-6 | 1 | 960 | 1027 |
| DZS0815 | 0.8×1.5 | 4~6 | YZO-18-6 | 1.1 | 960 | 1053 |
| DZS0918 | 0.9×1.8 | 4~6 | YZO-20-6 | 2 | 960 | 1086 |
| DZS0922 | 0.9×2.2 | 4~6 | YZO-20-6 | 2×1.5 | 960 | 1164 |
| DZS1018 | 1.0×1.8 | 4~6 | YZO-16-6 | 2×1.1 | 960 | 1215 |
| DZS1020 | 1.0×2.0 | YZO-16-6 | 2×1.1 | 960 | 1280 | |
| DZS1225 | 1.25×1.25 | 4~6 | YZO-20-6 | 2×2 | 960 | 1326 |
| DZS1530 | 1.5×3.0 | 4~6 | YZO-36-6 | 2×3 | 960 | 1875 |
| DZS21530 | 1.5×3.0 | 4~6 | 960 | 2056 | ||
| DZS1536 | 1.5×3.6 | 4~6 | 960 | 1935 |
1.Small motor power, only 1/4-1/5 of other vibrating screens;
2.Linear Vibrating screen of DZS series has high screen efficiency;
3.Adjustable screen angle;
4.The load transferred to the foundation is small and the foundation requires no special treatment;
5.Linear Vibrating screen of DZS series is made of wear-resistant rubber with long service life
